| File | Size | |
|---|---|---|
| Datasheet | 113.75KB | Download |
| IES file | 16.49KB | Download |
| Installation Instructions | 352.72KB | Download |
- Waterproof 12V AC/DC Marine Grade 316 Stainless Steel, Dimmable to 25%, 3W CREE LED Recessed Marker Deck light
- Suitable for install in a Dock, Decking, or Drywall
- Choice Round (-RD), Downlight (-DN), or 3-Way (-3W) Bezel
- Warm-White 3000K, 3W CREE LED
- Dimmable using a TRIAC type 12V LED driver, i.e illuminous EV-12V-120D
- Corrosion resistant for use in coastal areas
- Waterproof IP67
- NON-REPLACEABLE LED with up to 50,000 hours life makes fittings ideal for inaccessible locations
- Cool operating temperature
- Fitted with 2m of UL cable for connection to a 12V AC or DC CV LED driver (i.e illuminous EV-12V-80D)
- Push fit securing method
- 33 mm Body Diameter, Total Height 61.3mm, -RD Round Bezel is 46.5mm
- 1 year warranty
| Voltage / Power | |
| Input Voltage | 12V AC/DC |
| Constant Current / Voltage | Constant Voltage |
| Wattage | 3W |
| General | |
| Lumens | 30 |
| Bulb Color | Warm White |
| Bulb Included | Yes |
| Color Temperature K | 3000K |
| LED Qty | 1 |
| Dimmable | Yes |
| IP Rated | IP67 No Dust / Water to 3.3ft |
| submersible | No |
| Cable Included | Yes |
| Wiring (Series / Parallel) | Parallel |
| Location | Indoor/Outdoor |
| Profile | Recessed |
| Color | Silver |
| Material | Stainless Steel |
| Fixing | Floor/Wall |
| Angle | 60 |
| Dimensions | |
| Length | 2.41" |
| Diameter | 1.30" |
| Warranty | |
| 1 yr. | |
| Life (hrs) | 50000 |
LED Recessed Marker Deck Light S/S Dimmable 12V AC/DC 3W
- Brand: illuminous
- Product Code: EV-RECMKR-12V-RD
- Availability: In Stock
-
$24.99
